Print to all Windows supported plotter and printer devices. Poster mode for printing big format drawings on e.g. User defined header and footer for printing. TIFF, CALS, BMP, PNG and JPEG files can be added to a Workspace (for logos etc.).Ĭopy selected region to clipboard, and paste into another Windows application. Visibility of all loaded files can be set individually. No limit for number of files within a workspace (only limited by memory).
Highlight selected apertures in Gerber files.Īdd files of different formats to a single workspace. Support for absolute or relative coordinates. Measure distances, areas and perimeters, with our without snapping to pads and tracks.īoth metric and imperial coordinates supported. Query for entity information in Gerber, HPGL/2 and Excellon files. View, print, markup and convert Gerber, HPGL, HPGL/2, Excellon and raster formats.Ĭonvert Gerber, Excellon and HPGL/2 files to AutoDesk DXF, Adobe PDF and other formats.Ĭonvert multiple Gerber files to a multi layer PDF, DWF or DXF file. GerbView has mouse-controlled zoom in, zoom out, zoom area and panning. Markup elements can optionally be included in the conversion.
GerbView can rasterize single files, or whole workspaces, and save to one of the supported raster formats. See full list of supported formats below. GerbView can convert Gerber, HPGL, HPGL/2 and Excellon files to AutoDesk DXF, AutoDesk DWF, Adobe PDF and other formats. Markups will be stored in a separate file.
Markup elements like text, arrows, lines, images, ellipses and polygons can also be added to the workspace. The saved workspace will link to your design files, so only need to reload the workspace file to see the whole design. The workspace can be saved for later use. In GerbView you work with a workspace that can contain one or more files of the supported file formats. No more waiting for photoplots or your prototype circuit board, to see your true design. Gerbview will visualize your design, on the screen or in hardcopy. You can use GerbView to convert from the old RS274D Gerber standard to the new RS274X with embedded aperture information. GerbView supports both RS274D and RS274X (with embedded aperture information) Gerber formats. GerbView is an advanced but easy to use application that enables you to view, print, convert and markup Gerber, HPGL, HPGL/2, Excellon and raster files.
